EH Classic Electric Storage Water Heater
MODEL EH25
Spare Parts: 1 Year
Inner Tank: 3 Years
- Proven Water Heater with Millions of Installations Worldwide
- Cathodic Protection with Magnesium Anode Provided
- Wall-hung Installation Mounted Bracket Provided
Select Capacity
25
Gallons
40
Gallons
55
Gallons
75
Gallons
100
Gallons
Models
SKU EH25
Model Classic Electric Storage Water Heater EH
Tank Capacity 25
Fuel Electric
Energy Star Rated Yes
- Heater tank solid, long proven in millions of installation worldwide
- Insulation protection with CFC free polyurethane foam and epoxy colorbond jacket
- Cathodic protection with magnesium anode rod
- Incoloy 800 immersion type heating element provided
- Wall hung installation mounted bracket provided
- Dual thermal control with surface mounted on inner tank
- Temperature and pressure relief valve with highest protection against pressure built up
| Model | EH-25M | EH-40M | EH-55M | EH-75M | EH-100M | |
| Capacity (Litres) | 25 | 40 | 55 | 75 | 100 | |
| Mounting | Horizontal | |||||
| Heating Element Input (kW) (240V) | 3.0 | |||||
| Shipping Weight | 17 | 22 | 25 | 31 | 36 | |
| Operating Weight (Kg) | 42 | 62 | 80 | 106 | 136 | |
| Heater Dimension(mm) | Diameter | 370 | 370 | 370 | 370 | 458 |
| Length | 450 | 655 | 790 | 1130 | 962 | |
| Preset Temperature (°C) | 65 | |||||
| Approx*. Heat up Time to 65°C (mins) | 23 | 37 | 50 | 69 | 92 | |
*Heat up time is calculated based on a 3kW, incoming temperature of 25°C. All connections in 3/4"BSP Thread
Spare Parts: 1 Year
Inner Tank: 3 Years
